OKIO 2000W Automatic 4-axis Fiber Laser Welder
Product description
The OKIO 2000W automatic fiber laser welder is an advanced, 4-axis device designed for precise and rapid metal joining. Featuring a 2 kW MAX laser source and a CCD visual observation system with an HD monitor, the machine ensures excellent weld quality and full real-time process control. The inclusion of a fourth axis (rotary positioner) enables the welding of cylindrical components, while high positioning accuracy (±0.02 mm) makes it an ideal solution for demanding serial production.
Technical Data
| Parameter | Specification |
| Laser power | 2 kW |
| Number of axes | 4 (X, Y, Z + rotary positioner) |
| Rides (X / Y / Z) | 500 mm / 300 mm / 300 mm |
| Worktable dimensions | 350 mm × 450 mm |
| Ride speed (X, Y / Z) | 10 m/min / 5 m/min |
| Positioning accuracy | ± 0.02 mm |
| Rotation accuracy (4th axis) | ≤ 0.05 mm |
| Welding source | MAX (Fiber) |
| Vision system | CCD camera + HD monitor |
| Power supply / Consumption | 220V/380V / 7.5 kW |
| Device weight | 280 kg |
| Device dimensions | 500 × 1400 × 1900 mm |
| Country of origin | China |
Technical data
Number of axes: 4
Condition: new
Device weight: 280 kg
Welding source: MAX (Fiber)
Laser power: 2 kW
Rides (X / Y / Z): 500 mm / 300 mm / 300 mm
Worktable dimensions: 350 mm × 450 mm
Ride speed (X, Y / Z): 10 m/min / 5 m/min
Positioning accuracy: ± 0.02 mm
Rotation accuracy (4th axis): ≤ 0.05 mm
Vision system: CCD camera + HD monitor
Power supply / Consumption: 220V/380V / 7.5 kW
Device dimensions: 500 × 1400 × 1900 mm
Country of origin: China
Additional equipment: Chiller, welding head, mounting plate
Product overview
The OKIO 2000W automatic fiber laser welder is an advanced, 4-axis device designed for precise and rapid metal joining. Featuring a 2 kW MAX laser...
Read moreProduct price
Net price (PLN):
79 000 zł 67 500 zł
Net price (EUR):
18 900 € 15 800 €
Machine information
Status: Machine powered on
Location: Częstochowa
