Hyundai HS200 palletizing and feeding robot
Product description
Hyundai HS200 is a powerful unit designed for the heaviest industrial tasks. With an impressive payload capacity of 200 kg and a long reach of 2666 mm , this robot is ideal for palletizing, heavy part handling, and assembly line operations. The model combines high structural rigidity with smooth motion, which is critical when manipulating heavy loads.
Technical Specifications
| Parameter | Specification |
| Model | Hyundai HS200 |
| Year of Manufacture | 2010 |
| Number of Axes | 6 |
| Payload | 200 kg |
| Reach | 2666 mm |
| Repeatability | ± 0 , 2 mm |
| Controller | Hi5-N00 |
| Type | Material Handling / Palletizing Robot |
Key Advantages and Functionality
Versatile 6-Axis Design: Unlike typical palletizing robots (often 4-axis), the HS200 has 6 axes , providing full freedom of movement. This allows not only simple stacking but also complex part orientation, picking from different angles, and operation in confined spaces.
Large Working Area: With a reach of nearly 2.7 meters , the robot can handle tall pallet stacks and operate across multiple stations simultaneously (e.g., picking from one line and placing on two separate pallets).
Reliable Hi5-N00 Controller: Hyundai’s Hi5 series control system is stable and user-friendly, valued for simple programming of logistic tasks and easy diagnostics.
Precision with Heavy Loads: Despite handling weights up to 200 kg, the robot maintains repeatability of 0 , 2 mm, ensuring process stability and safe material handling.
